118 Ah NMC prismatic cell (nominal ~3.67 V), engineered for EV power systems.
Dimensions ~220.8 × 44.46 × 84.88 mm, weight approx. 1.87 kg.
Energy density ~231.6 Wh/kg, internal resistance ~0.3-0.5 mΩ (fresh cell).
Designed for ~1,350 cycles (@25 °C, 1 C → 80% SOH), operation down to –30 °C discharge.
| Item | Parameter | Test / Note |
|---|---|---|
| Nominal Capacity | 118 Ah | @1C typical discharge. |
| Nominal Voltage | ~3.67 V | Standard discharge average. |
| Operating Voltage Range | 2.8 – 4.35 V (T ≥ 0 °C) / 2.2 – 4.35 V (T < 0 °C) | From datasheet/third-party listing. |
| Internal Resistance | ≈ 0.3 – 0.5 mΩ | Fresh cell, ~70% SOC. |
| Dimensions (L × W × T) | ≈ 220.8 × 44.46 × 84.88 mm | From product specification. |
| Weight | ≈ 1.87 kg | 1870 ± 20 g typical. |
| Energy Density (Gravimetric) | ≈ 232 Wh/kg | Listed ~231.6 Wh/kg. |
| Cycle Life | ~1,350 cycles (25 °C, 1C → 80% SOH) | From non-engineered vendor claim. |
Note: The above table consolidates publicly-available data. For design/pack integration use, please verify values directly from CALB’s official datasheet or certified documentation.
Available with welding or nut terminals to suit various installation needs, with an interactive 3D model view.
The label shown on the battery cell is for visual demonstration only. The actual product will usually not have this label, only the essential numbering or identification.
Due to its unique properties, our NMC battery cell is widely used in fields requiring high energy density and strong power output:
Delivers the high energy density for maximum flight endurance and the high C-rate power for demanding drone payloads.
Our cells meet both BEV demands for maximum range (high energy density) and HEV needs for instant power and regeneration (high C-rate).
Meets the fast charge and discharge needs of buses for rapid energy replenishment.
Powered by superior energy density, our cells deliver greater power and extended range for high-performance electric yachts and hydrofoils.
Our products undergo strict testing and comply with multiple international standards to ensure quality and safety.
*Certification status may vary depending on region or project requirements. Relevant test reports or assistance for market-specific certification can be provided upon request.
