High-capacity NMC ternary lithium cell with a 3.7V nominal voltage, optimized for EVs, energy storage systems, and high-performance power applications.
Designed for over 1400 cycles with stable capacity retention, ensuring reliable long-term performance.
NMC ternary chemistry provides high energy density with stable performance and reliable safety.
Low internal resistance enables efficient energy output and high power performance.
| Item | Parameter | Remarks |
|---|---|---|
| Rated Capacity | 117 Ah | 1C Discharge |
| 117 Ah | 1/3C Discharge | |
| Rated Voltage | 3.7 V | Nominal |
| Rated Energy | ~438.7 Wh | 1/3C Discharge |
| Cell Weight | 1.805 ± 0.03 kg | / |
| Mass Energy Density | ~240 Wh/kg | 1/3C Discharge |
| Cell Volume | 0.75 L | (approximate) |
| Volume Energy Density | ~585 Wh/L | 1/3C Discharge |
| AC Internal Resistance (ACR) | ≤0.4 mΩ | 25% SOC, Room Temp, AC Impedance, 1000 Hz |
| Charging Temperature | -20 ~ 55 °C | / |
| Discharging Temperature | -30 ~ 55 °C | / |
| Storage Temperature | -40 ~ 60 °C | / |
| Fast Charging Time | ~36 min | 25°C, 20%–80% SOC |
| Voltage Range | 2.5 ~ 3.65 V | 0°C < T ≤ 55°C |
| 2.0 ~ 3.65 V | -30°C ≤ T ≤ 0°C |
Note: The above table consolidates multiple public datasheet & test sources. For engineering design or certification, please refer to the official Svolt datasheet or supplier‐contracted technical document and confirm operating voltage window & limit currents.
Available with welding or nut terminals to suit various installation needs, with an interactive 3D model view.
The label shown on the battery cell is for visual demonstration only. The actual product will usually not have this label, only the essential numbering or identification.
Due to its high energy density and superior power performance, our NMC power module is widely used in fields requiring lightweight design and robust output.
Delivers the high energy density for maximum flight endurance and the high C-rate power for demanding drone payloads.
Powered by superior energy density, our cells deliver greater power and extended range for high-performance electric yachts and hydrofoils.
Our cells meet both BEV demands for maximum range (high energy density) and HEV needs for instant power and regeneration (high C-rate).
Compact size and high power output enable agile movement in limited spaces.
Meets the fast charge and discharge needs of buses for rapid energy replenishment.
Our products undergo strict testing and comply with multiple international standards to ensure quality and safety.
*Certification status may vary depending on region or project requirements. Relevant test reports or assistance for market-specific certification can be provided upon request.
