The 4P3S structure delivers a derived nominal module capacity of 232Ah, supporting practical high-capacity battery platform development.
The module offers approximate nominal energy from 2.55kWh to 2.60kWh, making it suitable for compact and scalable EV battery integration projects.
The finished module dimensions follow the VDA355 format at 355*151*110±1mm for structured automotive pack design and system matching.
This NMC battery module is positioned for standardized module-based battery systems requiring balanced energy density and integration flexibility.
| Item | Parameter | Test Condition / Note |
|---|---|---|
| Product Type | Lithium-ion Battery Module | Module-level product |
| Chemistry | NMC | Commercial product positioning |
| Configuration | 4P3S | Module configuration |
| Format Family | VDA355 | Standardized module platform |
| Module Dimensions | 355*151*110±1mm | Finished module dimension |
| Nominal Capacity | 232Ah | Derived module value |
| Nominal Voltage | Approx. 11.01V | Based on 1C rated voltage |
| Nominal Voltage | Approx. 11.19V | Based on standard discharge voltage |
| Nominal Energy | Approx. 2.55kWh | Based on 212.86Wh x 12 cells at 1C basis |
| Nominal Energy | Approx. 2.60kWh | Based on 216.34Wh x 12 cells at standard discharge basis |
| Operating Voltage Range | 8.25-13.05V | 0C to 55C condition |
| Charge Temperature | -20C to 55C | Operating condition |
| Discharge Temperature | -30C to 55C | Operating condition |
| Storage Temperature | -40C to 60C | Storage condition |
| Fast Charging Time | <=20 min | 30%-80% SOC |
| Cycle Life | >2000 cycles at 25C | Life test result |
Module dimensions are 355*151*110±1mm. Module weight, housing layout, thermal design, and certification status should be confirmed according to the finished module design and target application requirements.
The 4P3S 232Ah VDA355 NMC battery module is designed in a standardized VDA355 format for compact pack layout and scalable battery system integration.
The finished module dimensions are 355*151*110±1mm. The label shown on the battery module is for visual demonstration only. The actual product will usually not have this label, only the essential numbering or identification.
Due to its unique properties, our VDA355 NMC battery Module is widely used in fields requiring ultra-high power and long life:
Our battery cells are used in electric vehicles to provide reliable, high-performance power for efficient transportation.
Provides robust power for electric motorcycles, enhancing speed and range for urban commuting and adventure.
Powers electric forklifts, ensuring high efficiency and long operating hours for logistics and warehouse operations.
Designed for electric boats, offering silent and powerful propulsion for marine applications.
Optimized for golf carts, providing long-lasting, dependable power for an enjoyable ride.
Powers construction vehicles, delivering reliable and durable energy for heavy-duty work environments.
Our products undergo strict testing and comply with multiple international standards to ensure quality and safety.
*Certification status may vary depending on region or project requirements. Relevant test reports or assistance for market-specific certification can be provided upon request.
